Widefield Microscopes

Upright with monochromatic camera

Zeiss Light Microscope AXIO Imager.D1

The Zeiss AxioImager.D1 is an upright microscope capable of  Brightfield,  DIC (Differential Interference Contrast) and Fluorescent Imaging. No motorized stage.


Microscope characteristics:

  • Camera: AxioCam MRm
  • Filters: 1-DAPI, 2-GFP; 3-CY3, 4-Rhodamine, 5- DIC Refl.light
  • Objectives: Epiplan-NEOFLUOTAR 10x/0,3 Ph1; LCI Plan-NEOFLUOTAR  ImmKorr 20x/0,8 Ph2; EC Plan-NEOFLUOTAR 40x/1,3 Oil, DIC; Plan-APOCHROMAT 63x/1,4 Oil, DIC
  • Serial Number: 3513000888, Internal Number: LMI-0971
  • Location: Tridomus, C-102

Leica Light Microscope DMRBE (upright)

Brightfield, Fluorescence using prepared slides

Microscope characteristics:

  • Filters: Y3 (Cy3), L4 (FITC), N2.1 (TRITC) A (DAPI), Y5 (Cy5)
  • Objectives: 5x PH0; 10x PH1; 20x/0,4 CORR PH1; 63/0,7 CORR PH2; 40x/0,55 CORR PH2;
  • Serial Number: 162821, Internal Number: LMI-0540
  • Location: House 42, R2220

Upright with color camera

Zeiss Light Microscope AXIO Imager.Z1

The Zeiss AxioImager Z1 is an upright microscope capable of  Brightfield,  DIC (Differential Interference Contrast) and Fluorescent Imaging.No motorized stage.

Microscope characteristics:

  • Filters: DAPI,GFP;Rhodamine
  • Objectives: EC PLnN 2,5x/0,075; EC PLnN 10x/0,3 DIC I; EC PLnN 20x/0,5 DIC II; EC PLnN 40x/0,75 DIC II; PLn Apo 63x/1,4 Oil DIC II; EC PLn 100x/1,3 Oil DIC II
  • Serial Number: 3512001627, Internal Number: LMI-0838
  • Location: Tridomus, C-104

Leica Light Microscope DMRE (upright)

Brightfield, Fluorescence using slides

Microscope characteristics:

  • Filters: 1-A (DAPI); 2-L5 (GFP); 3-N3 (TRITC), 4-Y5 (CY5); Position 5/6 are empty
  • Objectives: 2,5x/0,07 N PLAN; 5x/0,15 HC PL FLUOTAR; 10x/0,3 HC PL FLUOTAR; 20x/0,5 HC PL FLUOTAR; 40x/0,75 HCX PL FLUOTAR; 63x/1,32 HC PL APO; 100x/1,3 HC PL FLUOTAR
  • Serial Number: 229842, Internal Number: LMI-0702
  • Location: House 42, R3226

Inverted with monochromatic camera

Leica Light Microscope DMIRB (invers)

Brightfield, Fluorescence, Phase contrast of cell culture as well as interference contrast and polarisation plus video recording

Microscope characteristics:

  • Filters: 1-A (DAPI), 2-I3 (FITC), 3-N2.1 (TRITC)
  • Objectives: 5x/0,12 N PLAN;10x/0,25 N PLAN; 20x/0,4 N PLAN; 40x/0,55 N PLAN; 63x/0,7 PL FLUOTAR L; (ICT/P only with 20x and 40x)
  • Serial Number: 239370, Internal Number: LMI-0703
  • Location: House 42, R3226

Zeiss Light Microscope Axio Observer.Z1 (invers)

Fluorescence, Brightfield/Phase contrast, for Cell culture and prepared slides; Zen software drives the microscope and allows multi-dimensional data acquisition (multiple fluorescence channels, Z-stacks, time lapse and Tile scan). Additionally Z-stack with ApoTome to display with enhanced resolution is possible.

Microscope characteristics:

  • Filters: 49 (Dapi), 38 (GFP), 43 (DsRed), 63 HEmRFP, 50 (Cy5)
  • Objectives: PLnApo10x/0,45 PH1; LD PLnN 20x/0,4 PH2 DIC; PLnApo 20x/0,8 PH2 DIC; PLnApo 20x/0,8 PH2 DIC; Alpha PLnApo 63x/1,46 Oil PLnApo 40x/0,95 DIC III
  • Serial Number: 3851001556, Internal Number: LMI-0996
  • Location: House 42, R3226

Inverted with with color camera

Observer3 Colobri5, Zeiss

Microscope characteristics:

  • Location: Tridomus C-102
